CAMERA
Image Sensor:
1/2.8'' Progressive Scan CMOS Not Starlight Sensor
Lens:
Focal Length: 4 mm Aperture: F2.0
Field of View:
98° (Diagonal), 83°(Horizontal), 45°(Vertical)
Motion Range:
Pan & Tilt Mechanical Range: 340° & 70°
Night Vision:
850 nm IR LED (30 ft / 9 m)
Interface & Button:
1× RESET Button, 1× MicroSD Card Slot
VIDEO & AUDIO
Maximum Resolution:
2K 3MP (2304 x 1296 px)
Frame Rate:
15 fps
Video Compression:
H.264
Live View:
Yes
Image Enhancement:
3D DNR WDR
Audio Input & Output:
Built-in Mic & Speaker
Audio Communication:
Two-Way Audio with Noise Cancellation
Siren Volume:
88dB (Level measured at 4-inch/10-cm distance)
STORAGE
Local Storage:
MicroSD Card Slot on Camera (Up to 512 GB)
Cloud Storage:
Tapo Care Cloud Storage Services (Subscription required)
DETECTION & NOTIFICATIONS
AI Detection:
Motion Detection
Person Detection
BabyCry Detection
Activity Zones-Yes
Output Notification:
System Notification
System Notification with Snapshot (Tapo Care Services)
NETWORK
Network Connectivity:
Connect via Wi-Fi
RTSP-Yes
ONVIF-Yes
Certifications:
TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP
SECURITY
Security:
On-Device Machine Learning
128-bit AES Encryption with SSL/TLS
WPA/WPA2-PSK
POWER
Power Source:
9V DC Power Adapter
Input Voltage:
100-240 V, 50/60 Hz
Output Voltage:
DC9.0V/0.6A(DC Power)
GENERAL
Smart Integration:
Google Assistant, Amazon Alexa
Mounting Options:
Tabletop
Ceiling-Mounted
Operating Temperature:
0℃~40℃
Storage Temperature:
-20℃~60℃
Operating Humidity:
10%~90% RH, Non-condensing
Storage Humidity:
5%~90% RH, Non-condensing
Dimensions ( W x D x H ):
3.36×3.42×4.63 in
(85.4×86.8×117.7 mm)
Package Content:
1 x TC71 Camera
1 x Power Adapter
1 x Quick Start Guide
1 x Mounting Screws
1 x Mounting Template
1 x Mounting Anchors
Warranty:
2 Year Manufacturer limited warranty
